Pro Package

Pro Package

2199 /Sq.ft
Design
  • 2D Floor Plan
  • 3D Elevation
  • Structural Design
Drawings
  • Furniture Layout.
  • Site Center line drawings.
  • Underground Sump Layout.
  • Site Footings Layout.
  • Column Layout.
  • Plinth Beam Layout.
  • Staircase Layout.
  • Roof slab shuttering Layout.
  • Roof slab and beam drawings for every level.
Structure
  • Steel(JSW, Tata or equivalent).
  • Coarse Aggregates - 20mm Jelly & 40mm Jelly.
  • Concrete Blocks(Standard Solid Concrete blocks 6 inch for Exterior Walls & 4 inch for Interior Walls) Cement(ACC Cement, Ultratech Cement or equivalent of Grade - 43 or 53 Cement)
  • P sand for Plastering & M sand for Blockwork.
  • RCC Design Mix - Based on the Structural Design Floor Ceiling Height - We provide 10 feet ceiling height from Finished Floor level to the Finished Floor level).
  • The foundation will be planned based on the structural designs. We will provide 5 feet deep ecavation from road level for foundation work. If clayey/rocky strata are discovered at site during excavation then additional expenses may be incurred for men and material. Chargable beyond 5 feet.
  • Solid concrete blocks will be used for partition walls and Internal walls as defined in specification.
  • PCC (Plain Cement Concerete of 100 mm) to be provided below ground floor flooring.
  • Internal Plastering of cement mortar (1:4 ratio), external plastering of cement mortar (1:5 ratio) and ceiling plastering cement mortar (1:4 ratio) will be done. We will provide thickness of plaster will in 12mm applied in two coats.
  • In all the beam joints Chicken mesh will be used, column and masonry wall junction.
  • For the foundation if Retaining wall is required then it will be of extra cost.
  • Building Height of finished floor level in the ground floor will be up to 1.5 feet above the existing ground level.
  • If Water and rock found during the excavation, then it will be of extra with the labour charges Steel of Fe550 with 10mm for the footing, 12mm with 8mm stirrups for the plinth, 16mm and 12mmwith 8mm stirrups for columns, 16mm with 8mm stirrups for the beams, whereas for the slab 10mm (main bars) and the 8mm (distribution bars) will be used.
  • For the Doors and Windows opening we will provide Cut Lintel.
  • Plain Reinforced Cement Concrete Staircases with waist slab will be provided in the package and the rest models will be charged extra based on per each staircase step.
  • One course of size stone will be provided for the foundation.
  • We use Dr. Fixit for Waterproofing.
Kitchen
  • In Kitchen we provide Ceramic Wall Tiles of 4 feet above kitchen slab worth Upto Rs.60 per Sqft.
  • Main Sink Faucet will comes in the brand like Jaquar/Parryware/Hindware or Equivalent upto Rs.3000 and we will provide Faucet & Accessories with ISI Marked.
  • Kitchen Sink will be Stainless Steel Single Sink worth upto Rs. 7000.
  • Water purification inlet provision near kitchen sink will be provided.
  • Washing machine inlet & outlet provision for utility/dry balcony will be provided.
  • Exhaust fan provision will be provided if required in the kitchen.
  • In the package built-up area per 1000 sq.ft One Kitchen is included. Any Additional kitchens will be charged on the pro-rata basis.
  • Kitchen Granite will be provided value of upto Rs 140 per sqft of 38 mm..
  • We will provide 600mm width of Polished granite and thickness upto 38mm for the platform with the sink.
Washroom
  • Washroom Ceramic Wall Tiles will be provided till 7 feet height worth Upto Rs.55 per Sqft.
  • Sanitaryware & CP(Chrome Plated) Fittings (Upto Rs.50000 till 1000 sqft of built-up Area and will be calculated pro-data after. Company: Cera, Jaguar, Kohler, Hindware & Parryware)
  • CPVC Pipe(Ashirwad/Supreme or equivalent).
  • For the Washroom Accessories - EWC, Health Faucet, Overhead shower with accessories, 2 in 1 wall mixer.
  • Exhaust fan provision will be provided if required.
  • In the package built-up area per 500 sq. ft One washroom is included. Any Additional washroom will be charged on the pro-rata basis.
Door & Windows
  • We will provide Main Door of Burma Teak door along with the teak frame of 5 inch by 3 inch, worth Rs. 35000 including fixtures and the Door Thickness around 38 mm.
  • We will provide Internal Doors of Hardwood Panelled Door worth upto Rs. 11000 including the fixtures. Sal wood Frames will be provided for the door of 4inch by 2.5inch.
  • Windows will be provided in UPVC with glass shutters and mesh shutters will be in 3 track with 1 mesh.
  • Internal door thickness will be of 38mm. One number of aluminum or MS tower bolts and three numbers of MS Hinges for each door.
  • Windows(UPVC Windows with glass shutters and mesh shutters(3 track with 1 mesh)) worth Rs 400/sqft inclusive of fixtures and frames.
  • Main Door - The thickness of main door will be 38mm.
  • The thickness of the internal door will be 30mm
  • Eevery door will be provided with 1 number of aluminum / MS tower bolts, and 3 numbers of MS hinges.
  • Premium quality locks worth Rs 2000 of Europa/Godrej brand will be used. The door will be provided with 2 nos of brass towerbolt and 3 nos of brass hinges.
  • Doors will be provided with two numbers of 3 numbers of MS hinges and MS tower bolt.
  • For Main Doors and Room Doors, wall mounted magnetic stoppers will be provided.
  • Two coats of paint will be provided for the Sal wood.
  • Main door size will be of 3ft 6inchx7ft, Internal Room doors will be of 3ftx7ft and bathroom doors will be 2ft 6inches x 7feet.
  • Any extra requirement like Skylights for the cutouts and glass will be charged extra with fabrication charges.
  • The total opening area included in the package is 10% of the total built-up area.
  • For windows MS grill will be provided with maximum of 125mm spacing and the 10mm thick rod.
  • Flush door/membrane door will be used for the bathroom and it will be of waterproof and will provide bathroom doors with handle lock without keys.
  • Main door frame will be 0 ft 3inches x 0 ft 5inches, Room and bathroom frame size will be 2.5 inches x 4 inches.
Painting
  • For the Interior Painting JK Putty and Apcolite Premium Emulsion or equivalent will be provided.
  • For the Exterior Painting Asian Primer and Apex Exterior Emulsion Paint or equivalent will be provided.
  • Wall putty will be provided in 2 coats for Ceiling & Internal Walls.
  • One coat of primer and two coats of paint will be provided for the External walls.
  • For all MS grill works Enamel paint will be used. All MS steel painting will be provided with an anti-corrosion coat before painting.
Flooring
  • We provide Tiles or Granite of value upto Rs. 130 per sqft with GST for Living, Rooms and Dining Flooring.
  • For the Kitchen Flooring we provide the Tiles/Granite/Wooden flooring worth upto Rs100/sqft.
  • For the Balcony and Open Areas Flooring Anti-skid tiles will be provided of woth upto Rs.60 per sqft with GST.
  • We provide Sadarahalli Granite or Marble of value upto 80 /sqft for Staircase Flooring.
  • For the Parking Tiles area Anti-skid tiles will be provided of worth upto 50 per sqft.
  • Wall tiles will be fixed with the tile adhesive. Joints will be cleaned and grouted with the site-made grout.
  • Granite will have a minimum of thickness of 20 mm. If granite is used.
  • Skirting will be of tiles/granite. The height of skirting will not be less than 75mm.
  • Flooring/dado/skirting must to level/to plumb.
  • The laying of tiles/granite includes the size of 2ft by 2ft and any other size will be charged extra.
Electrical
  • Wires provided is of Fireproof wires by Finolex.
  • Switches and Sockets will be provided of Anchor Roma
  • MCB board will be provided (Anchor, Finolex or equivalent).
  • Rooms will be provided with three number of light point, One number of fan point, four number of plug points will be provide bedside the table & tv, study/dressing and air condition.
  • Electrical Points for the Bathroom will be provided with 2 numbers of light point, 1 numb er of geyser point, 1 number of plug point near sink.
  • Kitchen will be provided with 2 numbers of light point; 5 numbers of plug points for -refrigerator, mixer, oven, water purifier and plat form.
  • Living/Dining/Family hall each will be provide with 1 or 2 number of fan point, 4 number of light points, 4 number of plug points.
  • External Area like balcony, staircase, parking, terrace or passage which is other than built-up area will be provided light point and plug points at the suitable locations 1000 sqft, of 5 numbers.
  • In the Room, living area or Staircase two-way switches will be provided if required per bedroom 1 number.
  • Provision for television cable connection will be provided. One nos of calling bell will be provided for each house in the floor.
  • Earthing pit will be provided per 1000 sq. ft of one dwelling capacity of package built-up area.
  • Electrical points for the kitchen will be provided with 2 number of light points, 5 numbers of plug points for refrigerator, mixer, oven and water purifier.
Other Amenities
  • Overhead Tank will be provided with Sintex Double Layered 1500 Itrs.
  • Underground Sump(6000 litres).
  • Staircase Railing(MS Railing).
  • Block masonry will be provided for the underground sump.
  • Plain Cement Concerete(PCC) bed concrete will be provided of minimum thickness of 125mm at the bottom. The inside of the wall will be provided with chicken mesh plastering. Mild Steel cover plate will be provided of dimension 600 mm x 600 mm.
  • Parapet wall will be provided with the height of 3feet and 100mm thickness. Buttress will be provided at each 3m (10feet) of the length.
  • The weatherproof course will be provided at the terrace with one coat of waterproofing agent of Dr. Fixit brand or equivalent.
  • Staircase Railing of Mild Steel(MS) will be provided value of Rs. 150 per saft for material, painting, welding, fixing and finishing. (MS Railing)
  • Enamel Paint will be provided for the MS Grills for Windows worth Rs 180 per sq.ft.
  • If RCC Sump will be charged extra.
  • One Sajja will be provided in the bedroom and kitchen area.
  • Basic Elevation will be provided. If any extra designs like cladding, tiles and extra cement work,etc will be charged extra.
  • Electricity panel board and Bescom meter charges should be beared by the customer.
  • The overhead tank platform is not included in the package.
  • Rainwater harvesting will be provided as per BBMP norms at a nominal cost. (Not Part of the Package).
  • UPS wiring is not included in the package.
  • Anything not included as part of quotation, will be charged extra.
